JSSCD-80NC/X CNC High Speed metal cutting circular saw(Angled-Push)
This CNC high-speed circular saw delivers precision angled cuts for metal fabrication applications. Its 15-degree descending cut path technology reduces impact loads while producing smooth, planar cut faces essential for premium edge integrity.
The system features intelligent automation, robust clamping fixtures, and optimized architecture for processing various metal stock including tubing and structural sections with minimal fixture adjustments.
Key Features
- 15-degree downward cutting mechanism for reduced workpiece stress
- High-output drive system with robust clamping fixture
- Advanced CNC control with intuitive HMI interface
- Optional automated material handling module
- Precision-engineered for high-volume production
- Optimized for material yield and production efficiency
Technical Specifications
| Model |
Unit |
JSSCD-80NC/X |
| Mainframe dimensions |
mm |
1998*2273*1808 |
| Bar & round pipe |
mm |
10-80 |
| Angle bar & square bar |
mm |
15-60 |
| Saw blade size |
mm |
φ300*1.75*2.0*φ32 |
| Spindle motor power |
KW |
7.5(6P) |
| Spindle speed |
rpm |
30-150 |
| Feeding servo motor power |
KW |
1.5 |
| Material removal length at the front end |
mm |
≥10 |
| Single feeding length (repeatable) |
mm |
10-850(Reversible feeding mechanism) |
| Hydraulic drive motor power |
KW |
1.5(4p) |
| Rated pressure of the hydraulic system |
mpa |
4-5 |
| Hydraulic oil capacity |
L |
70 |
Operational Benefits
• Elevates Material Yield: Minimizing scrap through optimized cutting strategies
• Accelerates Production Cycles: Reducing processing time per component
• Streamlines Delivery Timelines: Enabling faster order fulfillment
• Enhances Labor Efficiency: Freeing skilled personnel for higher-value tasks
Frequently Asked Questions
Q1: Are you a manufacturer or a trading company?
A: We are a professional manufacturer of saw blade grinders with a 30,000 square meter factory and dedicated technical team.
Q2: Where is your factory located?
A: Our factory is located in Nantong City, Jiangsu Province, China, approximately 1.5 hours from Shanghai Hongqiao station.
Q3: What is your factory acceptance test method?
A: We perform test cuts with customer-provided samples and provide detailed cutting data along with video documentation.
Q4: What is your method of transaction?
A: We typically use FOB (Free On Board) transactions.
Q5: How about your delivery time?
A: Delivery typically takes 7-60 work days depending on order specifics.
Q6: How about the payment term?
A: Standard terms are 30% deposit with 70% balance paid before shipment.
Q7: Does the band saw blade have any international certifications?
A: Yes, we have obtained CE and ISO international certifications.
